RHINO G2 TMA

Main pumped products

Composition

Working principle

1 | Stopping phase
A small quantity of liquid is trapped into the pump to enable the next starting

2 | Priming Phase
the impeller gives an accurate circulation of air + liquid mix moving air from the suction pipe to the discharge side in the atmosphere.

3 | Pumping phase
After the air is removed from the suction side, the tube is flooded by the liquid, and the pumping phase can start.


Applications

RHINO self-priming pumps are ideal for negative suction aspiration operations from a basement tank to truck or surface tank, for unloading and transferring waste collection wells, and other processes using heavy liquids like:

  • Chemical industry

  • Mining industry

  • Power plants

  • Food and Beverage industry

  • Pulp and paper

Request info

  • Magnetic-driven technology

  • Unique ARGAL solution: biphasic impeller allowing to prime both high-density and high-vapor-pressure liquids

  • Start-up with empty pipes

  • Capacities up to 17m3/h

  • Very fast priming time

  • High suction length (up to -6m)

  • Highly corrosive-resistant materials: PP and E-TFE

  • ATEX Zone 2 (Serie II 3/3 GD IIB T4) conformity

  • 3 motor executions available according to the liquid specific gravity: "N" standard - 1,1 ; "P" powered - 1,35 ; "S" superpowered - 1,8
